Milano Alpha - White Vertical Flat Panel Designer Radiator - 1600mm x 280mm
Featuring flat panels for a minimal look and a hard-wearing white powder coated finish that teams well with any decor, the Milano Alpha 1600 x 280mm vertical designer radiator is the perfect choice for modern interiors.
Crafted from premium quality steel for guaranteed durability, the Alpha radiator will bring sophisticated style and elegance to your bathroom, kitchen, living room or bedroom and keep it luxuriously warm.
The impressive hourly heat output means your chosen room will be quickly and efficiently transformed into a space that feels superbly cosy and inviting.
What's Included?
- Wall fixings
- Wall plugs
- Blanking and bleed plug
Alpha Designer Radiator Features:
- Dimensions: 1600mm x 280mm x 47mm
- 2217 BTU’s (650 Watts)
- High quality white powder coated finish
- Features 4 vertical single panels
- Built to last: 1.5mm thick steel for guaranteed quality
- Tested and certified: BS EN 442 standards
- ISO9001:2008 registered manufacturer
- CE marked
Range | Alpha |
---|---|
Orientation | Vertical |
Style | Modern |
Type | Vertical Designer Radiator |
Finish | White |
RAL Code | 9016 |
Installation Type | Central Heating |
Material | Steel |
Floor to Centre of Tapping (mm) | 300 (approx) |
Pipe Centres (mm) | 370 (approx) |
Wall to Centre Tapping (mm) | 38 |
Volume (litres) | 3.5 |
Inlet Connection | 1/2" |
Maximum Water Pressure | 10 Bar |
BTU at Delta T30 | 815 |
BTU at Delta T50 | 1583 |
BTU at Delta T65 | 2226 |
Watts at Delta T30 | 239 |
Watts at Delta T50 | 464 |
Watts at Delta T65 | 652 |
Included | Fixing Pack, Vent and Bleeding Plug |
Height (mm) | 1600 |
Width (mm) | 280 |
Depth (mm) | 46 |
Projection from Wall (mm) | 64 |
Product Weight (kg) | 10.24 |
Certification | CE |
Guarantee | 20 Years |
Finish | White |
